LTST-E133HEGBK
ActiveDiodes Inc
LED RGB CLEAR SMD
LTST-E133HEGBK
ActiveDiodes Inc
LED RGB CLEAR SMD
Description
General part information
LTST-E133HEGBK
Red, Green, Blue (RGB) 622nm Red, 526nm Green, 470nm Blue LED Indication - Discrete 0505 (1313 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | LTST-E133HEGBK |
|---|---|
| Color | Blue (RGB), Green, Red |
| Configuration | Discrete |
| Height (Max) | 0.5 mm |
| Interface | Serial |
| Lens Color | Colorless |
| Lens Length | 1.3 mm |
| Lens Style | Rectangle, Flat Top |
| Lens Transparency | Clear |
| Lens Width | 1.3 mm |
| Millicandela Rating (Blue) | 222.5 mcd |
| Millicandela Rating (Green) | 980 mcd |
| Millicandela Rating (Red) | 445 mcd |
| Millicandela Rating Colors | Blue, Green, Red |
| Mounting Type | Surface Mount |
| Number of LEDs | 1 |
| Package / Case | 0505 (1313 Metric) |
| Size / Dimension Length | 1.3 mm |
| Size / Dimension Width | 1.3 mm |
| Viewing Angle | 120 ° |
| Wavelength - Dominant (Blue) | 470 nm |
| Wavelength - Dominant (Green) | 526 nm |
| Wavelength - Dominant (Red) | 622 nm |
| Wavelength - Dominant Color | Red, Green, Blue |
