ANT-2.4-CN-N
ObsoleteTE Connectivity AMP Connectors
RF ANT 2.4GHZ CORNER REFL BRK MT
ANT-2.4-CN-N
ObsoleteTE Connectivity AMP Connectors
RF ANT 2.4GHZ CORNER REFL BRK MT
Description
General part information
ANT-2.4-CN-N
2.4GHz Corner Reflector RF Antenna 2.4GHz ~ 2.483GHz 10.5dB N Type Bracket Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | ANT-2.4-CN-N |
|---|---|
| Antenna Type | Corner Reflector |
| Features | Cable, 221mm |
| Frequency (Center/Band) | 2.4 GHz |
| Frequency Group | UHF |
| Frequency Group Maximum (UHF) | 3 GHz |
| Frequency Group Minimum (UHF) | 2 GHz |
| Frequency Range (Max) | 2.483 GHz |
| Frequency Range (Min) | 2.4 GHz |
| Gain | 10.5 dB |
| Height (Max) | 14.2 in |
| Mounting Type | Bracket Mount |
| Number of Bands | 1 |
| Power - Max | 100 VA |
| Termination | N Type |
| VSWR | 1.5 |
