S0AL500A101M1S2001W
ActiveJohanson Technology Inc.
CAP CER 100PF 50V GBBL SMD
S0AL500A101M1S2001W
ActiveJohanson Technology Inc.
CAP CER 100PF 50V GBBL SMD
Description
General part information
S0AL500A101M1S2001W
100 pF ±20% 50V Ceramic Capacitor GBBL Nonstandard SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | S0AL500A101M1S2001W |
|---|---|
| Applications | High Frequency, RF, Microwave |
| Capacitance | 100 pF |
| Features | Single Layer, Bonding Mountable, Low Loss, Low Profile, High Q |
| Mounting Type | SLCC, Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard SMD |
| Size / Dimension Length | 0.015 in |
| Size / Dimension Width | 0.015 in |
| Temperature Coefficient | GBBL |
| Thickness (Max) | 0.009 in |
| Tolerance | 20 % |
| Voltage - Rated | 50 V |
