SM4W102
ObsoleteVishay Dale
TRIMMER 1K OHM 0.25W J LEAD TOP
SM4W102
ObsoleteVishay Dale
TRIMMER 1K OHM 0.25W J LEAD TOP
Description
General part information
SM4W102
1 kOhms 0.25W, 1/4W J Lead Surface Mount Trimmer Potentiometer Cermet 12.0 Turn Top Adjustment
Technical Specifications
Parameters and characteristics for this part
| Specification | SM4W102 |
|---|---|
| Adjustment Type | Top Adjustment |
| Mounting Type | Surface Mount |
| Number of Turns | 12 turns |
| Power (Watts) | 250 mW |
| Power (Watts) Options | 1/4W |
| Resistance | 1 kOhm |
| Resistive Material | Cermet |
| Size / Dimension Length | 0.193 in |
| Size / Dimension Shape | Rectangular |
| Size / Dimension Width | 0.146 in |
| Temperature Coefficient | 100 ppm/°C |
| Termination Style | J Lead |
| Tolerance | 10 % |
