CCTN58-15HR2B
ActivePasternack
CA BNCM RA/BNCM RA RG58/U 15'
CCTN58-15HR2B
ActivePasternack
CA BNCM RA/BNCM RA RG58/U 15'
Description
General part information
CCTN58-15HR2B
Cable Assembly Coaxial BNC to BNC RG-58 180.0" (4.6m) 15.0'
Technical Specifications
Parameters and characteristics for this part
| Specification | CCTN58-15HR2B |
|---|---|
| 1st Connector | Right Angle, BNC Plug |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Male |
| 2nd Connector | BNC Plug, Right Angle |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Male |
| Cable Impedance | 50 Ohms |
| Cable Type | RG, 58 |
| Color | Gray |
| Connector Impedance | 50 Ohms |
| Length | 180 in |
| Overall Impedance | 50 Ohms |
| Style | BNC |
