3-640443-2
ActiveIDC CONNECTOR, IDC RECEPTACLE, FEMALE, 2.54 MM, 1 ROW, 2 CONTACTS, CABLE MOUNT

3-640443-2
ActiveIDC CONNECTOR, IDC RECEPTACLE, FEMALE, 2.54 MM, 1 ROW, 2 CONTACTS, CABLE MOUNT
Description
General part information
3-640443-2
The 3-640443-2 is a 8-way 1-row Economy Power Connector Assembly with matte tin-plated copper alloy contacts. The wire-to-board connector comes with nylon housing and locking lance. This MTA-100 connector accepts 28AWG discrete and ribbon cable wire. Only one wire to be terminated into an IDC contact slot. It can be used with MTA-100 headers. Benefits derived from the MTA-100 system include increased quality and ease of handling such as one-step assembly, no wire stripping, no contact damage, reduced wiring errors, simpler tooling, simple maintenance and repair.
Technical Specifications
Parameters and characteristics for this part
| Specification | 3-640443-2 |
|---|---|
| Cable Termination | IDC |
| Color | Green |
| Connector Type | Receptacle |
| Contact Finish | Tin |
| Contact Finish Thickness | 80 µin |
| Contact Type | Female Socket |
| Fastening Type | Locking Ramp |
| Features | Closed End |
| Mounting Type | Right Angle, Free Hanging (In-Line) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Pitch | 0.1 in |
| Wire Gauge | 28 AWG |
| Wire Type | Ribbon Cable, Discrete |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
