Description
General part information
SQF-SMSV2-128GDSDE
Solid State Drive (SSD) FLASH - NAND (TLC) 128GB SATA III mSATA
Technical Specifications
Parameters and characteristics for this part
| Specification | SQF-SMSV2-128GDSDE |
|---|---|
| Form Factor | mSATA |
| Memory Size | 128 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Height | 4.2 mm |
| Size / Dimension Length | 2 in |
| Size / Dimension Width | 30 mm |
| Speed - Read | 550 MB/s |
| Speed - Write | 520 MB/s |
| Type | SATA III |
