CFM-8020CF-125-273
ActiveSame Sky (Formerly CUI Devices)
DC FANS DC AXIAL FAN, 80 MM SQUARE, 20 MM, 12 VDC, OMNICOOL, 2500 RPM, 24.52 CFM
CFM-8020CF-125-273
ActiveSame Sky (Formerly CUI Devices)
DC FANS DC AXIAL FAN, 80 MM SQUARE, 20 MM, 12 VDC, OMNICOOL, 2500 RPM, 24.52 CFM
Description
General part information
CFM-8020CF-125-273
Fan Tubeaxial 12VDC Square - 80mm L x 80mm H omniCOOL™ Magnetic Sleeve 24.5 CFM (0.685m³/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-8020CF-125-273 |
|---|---|
| Air Flow | 24.5 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | omniCOOL™ Magnetic Sleeve |
| Current Rating | 0.08 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 40000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 27.4 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 960 mW |
| RPM | 2500 RPM |
| Size / Dimension Height | 80 mm |
| Size / Dimension Length | 80 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.07 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Voltage Range (Max) | 13.2 VDC |
| Voltage Range (Min) | 10.8 VDC |
| Width | 20 mm |
