200V-3-2-5/25-vac-69
ActiveNOSHOK, Inc.
MECHANICAL PRESSURE SWITCH
200V-3-2-5/25-vac-69
ActiveNOSHOK, Inc.
MECHANICAL PRESSURE SWITCH
Description
General part information
200V-3-2-5/25-vac-69
MECHANICAL PRESSURE SWITCH
Technical Specifications
Parameters and characteristics for this part
| Specification | 200V-3-2-5/25-vac-69 |
|---|---|
| Applications | Industrial Automation |
| Maximum Pressure | 350 PSI |
| Operating Pressure (Max) | 25 PSI |
| Operating Pressure (Min) | 5 PSI |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -20 °C |
| Output Type | SPDT |
| Package / Case | Threaded, Cylinder |
| Port Diameter | 0.25 " |
| Port Feature | NPT |
| Port Gender | Male |
| Port Style | Threaded |
| Pressure Type | Switch |
| Termination Style | M12 |
