ELPM 75 POP
Sensor
Technical Specifications
Parameters and characteristics for this part
| Specification | ELPM 75 POP |
|---|---|
| Actuator Type | Linear Slide |
| For Measuring | Linear Position |
| Linear Range (Max) | 75 mm |
| Linear Range (Min) | 0 mm |
| Linearity Tolerance | 1 % |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -40 °C |
| Output | Analog Voltage |
| Package / Case | Module |
| Resistance | 7.5 kOhm |
| Technology | Resistive |
| Termination Style | Cable |
| Voltage - Supply | 24 VDC |
