T4151110003-003
ActiveTE Connectivity AMP Connectors
RPC-M12-MS-3CON-PVC-1.5
T4151110003-003
ActiveTE Connectivity AMP Connectors
RPC-M12-MS-3CON-PVC-1.5
Description
General part information
T4151110003-003
M12 Pigtail Cable Assembly, 3 Position, Cable Assembly Length 1.5 m [4.9 ft], Sensor/Actuator, A Code, M12 Plug End A, Single Ended, Nylon GF
Technical Specifications
Parameters and characteristics for this part
| Specification | T4151110003-003 |
|---|---|
| 1st Connector Gender | Male Pins |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 3 positions |
| 1st Connector Number of Positions Loaded | All |
| 1st Connector Orientation | A |
| 1st Connector Shell Size - Insert | M12 |
| 1st Connector Type | Receptacle |
| 2nd Connector Type | Wire Leads |
| Assembly Configuration | Standard |
| Cable Material | Polyvinyl Chloride (PVC) |
| Cable Type | Round |
| Color | Black |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Length | 9.84 ft |
| Shielding | Unshielded |
| Usage | Industrial Environments |
