Specification	983-0SE 14-07 SN-L

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Size	16 S
Contact Type	Crimp
Fastening Type	Threaded
Features	Self Locking
Housing Color	Silver
Ingress Protection	Environment Resistant
Insert Material	Thermo-setting Polymer
Mounting Feature	Flange
Mounting Type	Panel Mount
Note	Contacts Not Included
Number of Positions	7
Operating Temperature (Max)	500 °F
Operating Temperature (Min)	-65 °C
Orientation	N (Normal)
Shell Material	Stainless Steel
Shell Size - Insert Length	14 mm
Shell Size - Insert Width	7 mm
Shielding	Unshielded
Type	For Female Sockets

DEUTSCH 983 Series Series

...

Part	Contact Material	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Insert Material	Termination	Shielding	Shell Material	Number of Positions	Color	Orientation Angle	Features	Fastening Type	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Connector Type	Ingress Protection	Applications	Contact Finish - Mating	Primary Material	Shell Size - Insert Width	Shell Size - Insert Length	Housing Color	Orientation	Contact Size	Contact Type	Type	Note	Mounting Feature	Contact Shape
TE Connectivity AMP Connectors 983-15 KE 7-12-03 SN-L
TE Connectivity AMP Connectors 983-6SE 24-30 P6 A1208	Copper Alloy	24	30	Polymer	Crimp	Shielded	Stainless Steel	30	Silver	6 °	Coupling Nut Self Locking	Threaded	500 °F	-65 °C	Free Hanging (In-Line)	Male Pins Plug	Environment Resistant	Aviation	Gold	Metal
TE Connectivity AMP Connectors 983-15 SE 7-14-07 PN-L
TE Connectivity AMP Connectors 983-7RS 20-39 P6 L
TE Connectivity AMP Connectors 983-15 KE 2-10-05 SN-L				Thermo-setting Polymer		Unshielded	Stainless Steel	5			Self Locking	Threaded	500 °F	-65 °C	Panel Mount	Receptacle Housing	Environment Resistant				5 mm	10 mm	Silver	N (Normal)	20	Crimp	For Female Sockets	Contacts Not Included	Flange	Circular
TE Connectivity AMP Connectors 983-15 KV 7-14-07 P6 L
TE Connectivity AMP Connectors 983-6S 16-24 SN-L
TE Connectivity AMP Connectors 983-6KE 12-12 SN-L
TE Connectivity AMP Connectors 983-6SE 24-30 PN	Copper Alloy	24	30	Polymer	Crimp	Shielded	Stainless Steel	30	Silver		Coupling Nut Self Locking	Threaded	500 °F	-65 °C	Free Hanging (In-Line)	Male Pins Plug	Environment Resistant	Aviation	Gold	Metal				N (Normal)
TE Connectivity AMP Connectors 983-6SE 16-24 SN	Copper Alloy	16 S	24	Polymer	Crimp	Shielded	Stainless Steel	24 pos	Silver		Coupling Nut Self Locking	Threaded	500 °F	-65 °C	Free Hanging (In-Line)	Female Sockets Plug	Environment Resistant	Aviation	Gold	Metal				N (Normal)
