SR405A683KAA
ActiveKYOCERA AVX
CAP CER 0.068UF 50V NP0 RADIAL
SR405A683KAA
ActiveKYOCERA AVX
CAP CER 0.068UF 50V NP0 RADIAL
Description
General part information
SR405A683KAA
0.068 µF ±10% 50V Ceramic Capacitor C0G, NP0 Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | SR405A683KAA |
|---|---|
| Applications | General Purpose |
| Capacitance | 0.068 µF |
| Height - Seated (Max) | 0.46 in |
| Lead Spacing | 0.2 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.4 in |
| Size / Dimension Width | 0.15 in |
| Temperature Coefficient | NP0, C0G |
| Tolerance | 10 % |
| Voltage - Rated | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
