Specification	B25631B2306K000

Applications	DC Filtering, DC Link
Capacitance	30 µF
ESR (Equivalent Series Resistance)	2.5 mOhm
Height - Seated (Max)	2.559 in
Lead Spacing	1.772 in
Mounting Type	Chassis Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Radial
Size / Dimension Diameter	3.346 in
Termination	Threaded, Male
Tolerance	10 %
Voltage Rating - DC	2 kVDC
